Tplink TL-WA701ND 150Mbps Wireless N Access Point
Complying with the IEEE 802.11n standard, TL-WA701ND can easily establish a wireless network and get up to 9X the speed and 4X the range of conventional 11g products. With Align™ technology based on the IEEE 802.11n 1-stream specification shows improved performance over the existing 802.11g technology, TL-WA701ND delivers performance enhancements, allowing you to have a more joyful surfing experience, including sharing files, watching streaming media.
Supports multiple operating modes (Access Point, Multi-SSID, Client, Universal/ WDS Repeater, Bridge with AP) to enable various wireless applications to give users a more dynamic and comprehensive experience when using their AP. Multiple operating mode also helps you easily to build wireless network for hard-to-wire locations or eliminating wireless dead zone.
The TL-WA701ND is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office
Hardware Features.
- Interface: 1 10/100Mbps Auto-Sensing RJ45 Port(Auto MDI/MDIX, Passive PoE)
- Button: WPS Button
Reset Button
Power On/Off Button - External Power Supply: 9VDC / 0.6A
- Wireless Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- Dimensions ( W x D x H ): 7.1 ×4.9× 1.4 in. (181 ×125 ×36mm)
- Antenna Type: 5 dBi Detachable Omni Directional Antenna (RP-SMA)
Wireless Features.
- Frequency: 2.4-2.4835GHz
- Signal Rate: 11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic) - Reception Sensitivity: 130M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER - Transmit Power: <20dBm (EIRP)
- Wireless Modes: AP Mode, Multi-SSID Mode,
Client Mode, Repeater Mode (WDS / Universal ),
Bridge Mode - Wireless Functions: WDS Bridge, WMM
- Wireless Security: SSID Enable/Disable MAC Address Filter 64/128/152-bit WEP Encryption WPA/WPA2/WPA-PSK/WPA2-PSK (AES/TKIP) Encryption
- Management: SNMP
- Advanced Functions: Up to 30 meters Passive PoE is supported
Other Features.
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 10, MAC OS, NetWare, UNIX or Linux.
- Environment: Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
