Hikvision DS-7732NXI-K4/16P 32-ch 1.5U 16 PoE 4K NVR

The Hikvision DS-7732NXI-K4/16P is a high-performance Network Video Recorder (NVR) designed for versatile and reliable security surveillance. Engineered to support up to 32 IP camera inputs, this NVR provides seamless plug-and-play functionality with 16 built-in Power-over-Ethernet (PoE) interfaces, allowing for effortless setup and power management of connected cameras. With support for ultra-high-definition recording and playback, it ensures optimal visual clarity and efficient video data handling. Leveraging Hikvision’s advanced AcuSense technology, this NVR reduces manual monitoring effort and enhances security precision, minimizing false alarms and lowering overall surveillance costs.

Key Features:

• 32-Channel IP Camera Support: Connect and monitor up to 32 IP cameras simultaneously.
• 16 PoE Interfaces: Simplify installation with plug-and-play functionality, providing power and network connection via PoE for 16 cameras.
• Supports Multiple Video Formats: Compatible with H.265+/H.265/H.264+/H.264 video formats for efficient storage and versatile compatibility.
• High Decoding Capacity:
  • Supports 2 channels at 12 MP
  • 3 channels at 8 MP
  • 6 channels at 4 MP
  • 12 channels at 1080p resolution
• 256 Mbps Incoming Bandwidth: Handles high data loads, supporting large-scale monitoring setups without compromising performance.
• AcuSense Technology: Equipped with AI-powered analytics to reduce false alarms by distinguishing human and vehicle targets from other moving objects.
• 4K Ultra HD Resolution: Supports up to 4K resolution for crystal-clear video playback and precise detail in surveillance footage.

Detailed Specifications:

• Model: DS-7732NXI-K4/16P
• Device Type: Network Video Recorder (NVR)
• Video Inputs:
  • Up to 32 IP camera inputs
  • Plug & Play with 16 PoE interfaces
• Video Output:
  • HDMI and VGA output with up to 4K resolution
• Decoding Capacity:
  • 2-ch at 12 MP, 3-ch at 8 MP, 6-ch at 4 MP, or 12-ch at 1080p
• Compression:
  • H.265+/H.265/H.264+/H.264 for efficient storage and playback
• Network Throughput:
  • Incoming Bandwidth: 256 Mbps
  • Outgoing Bandwidth: 160 Mbps
• Storage:
  • Supports up to 4 HDDs with 10 TB each, totaling up to 40 TB storage
  • RAID 0, RAID 1, RAID 5, and RAID 10 configurations
• Audio:
  • 2-way audio supported, with audio input and output ports
• Alarm:
  • 16-ch alarm inputs and 4-ch alarm outputs
• Intelligent Analytics:
  • AcuSense technology with AI-powered human/vehicle detection
• Power Supply:
  • Built-in 16-port PoE switch for efficient power management of connected cameras
  • Power Consumption: ≤ 20 W (without HDD or PoE)
• Dimensions: 1.5U chassis, suitable for standard rack mounting
• Weight: Approx. 5 kg (without HDD)
• Operating Conditions: -10°C to 55°C, humidity ≤ 90% (non-condensing)

This Hikvision DS-7732NXI-K4/16P NVR is a highly scalable, efficient, and intelligent solution ideal for businesses, warehouses, and institutions seeking robust and reliable surveillance infrastructure with advanced analytics capabilities.
