D-Link 28 Port Smart Managed Layer 2+ Gigabit Ethernet Switch (DGS-1210-28)
D-Link 28 Port Smart Managed Layer 2+ Gigabit Ethernet Switch (DGS-1210-28) is designed for small and medium-sized businesses. It is part of D-Link’s DGS-1210 series of Web Smart Switches, which offer an affordable solution with essential features and reliable performance.

Key Features of the D-Link 28 Port Smart Managed Layer 2+ Gigabit Ethernet Switch (DGS-1210-28)
- 24x 10/100/1000 Mbps Gigabit Ethernet ports for high-speed network connectivity.
- 4x Gigabit SFP (Small Form-factor Pluggable) ports for fiber uplink, allowing for long-distance communication and increased network scalability.
- Layer 2+ functionality, including support for VLANs (Virtual Local Area Networks), QoS (Quality of Service), and IGMP Snooping, which helps optimize network performance and manage multicast traffic.
- Advanced security features, such as Access Control Lists (ACLs), port security, and D-Link Safeguard Engine to protect the network from threats and unauthorized access.
- Web-based management interface for easy configuration and monitoring of the switch, as well as support for SNMP (Simple Network Management Protocol) for integration with network management systems.
- Green Ethernet technology, which includes features such as energy-efficient Ethernet (EEE), port shutoff, and cable length detection to reduce power consumption and operating costs.
- Auto Surveillance VLAN and Auto Voice VLAN to simplify the deployment of IP surveillance and VoIP applications.
- Loopback detection and broadcast storm control to prevent network issues caused by loops or excessive traffic.
Key specifications for D-Link 28 Port Smart Managed Layer 2+ Gigabit Ethernet Switch (DGS-1210-28)
- Device Type: Smart Managed Ethernet Switch
- Form Factor: Rack-mountable (1U)
- Ports:
- 24x 10/100/1000 Mbps Gigabit Ethernet ports (RJ-45)
- 4x Gigabit SFP (Small Form-factor Pluggable) ports (fiber uplink)
- Switching Capacity: 56 Gbps
- MAC Address Table: 16K entries
- Packet Buffer Memory: 4.1 Mbits
- Forwarding Rate: 41.7 Mpps (million packets per second)
- VLAN Support: 802.1Q, up to 256 VLANs, and VLAN ID range from 1-4094
- Quality of Service (QoS): 802.1p, 4 priority queues per port
- Security Features:
- Access Control Lists (ACLs)
- Port Security
- D-Link Safeguard Engine
- Management Features:
- Web-based management interface
- SNMP v1, v2c, v3
- RMON (Remote Monitoring) support
- LLDP (Link Layer Discovery Protocol)
- Layer 2+ Features:
- IGMP Snooping (v1, v2, and v3)
- Spanning Tree Protocol (STP, 802.1D) and Rapid Spanning Tree Protocol (RSTP, 802.1w)
- Link Aggregation (802.3ad)
- Green Ethernet Features:
- Energy-Efficient Ethernet (EEE, 802.3az)
- Port Shutoff
- Cable Length Detection
- Auto Surveillance VLAN and Auto Voice VLAN
- Loopback Detection and Broadcast Storm Control
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Power Supply: Internal AC power supply, 100-240V AC, 50/60 Hz
- Power Consumption: Maximum 19.7W
These specifications make the D-Link DGS-1210-28 a versatile and efficient solution for small and medium-sized businesses looking for a cost-effective, high-performance Ethernet switch.
