TP-Link ES205GP Omada 5-Port Gigabit Easy Managed PoE+ Switch

TP-Link ES205GP Omada 5-Port Gigabit Easy Managed PoE+ Switch

The TP-Link ES205GP Omada 5-Port Gigabit Easy Managed PoE+ Switch is a compact network switch designed for small businesses, offices, retail environments, and surveillance systems that require reliable Gigabit connectivity with Power over Ethernet. It combines five Gigabit Ethernet ports, four IEEE 802.3af/at-compliant PoE+ ports, cloud-based management, and essential Layer 2 management features, making network deployment and maintenance straightforward.

Product Overview

The TP-Link ES205GP provides five 10/100/1000 Mbps RJ45 ports, including four PoE+ ports that deliver both power and data through a single Ethernet cable. With a total PoE power budget of 65 W and up to 30 W per PoE port, it supports compatible devices such as IP cameras, wireless access points, and VoIP phones without requiring separate power supplies.

In addition, the switch integrates with the Omada platform for centralized cloud management through a web interface or the Omada app. It also includes VLAN, Quality of Service (QoS), IGMP Snooping, automatic loop prevention, PoE Auto Recovery, and Port Isolation, helping administrators build a reliable and efficient network.

Key Features

• Provides five Gigabit RJ45 ports, delivering high-speed wired connectivity for business networks.
• Includes four IEEE 802.3af/at-compliant PoE+ ports, allowing compatible devices to receive power and data through a single Ethernet cable.
• Supports a 65 W PoE power budget, with up to 30 W available on each PoE+ port for compatible powered devices.
• Offers plug-and-play installation, enabling quick deployment while providing additional management features when required.
• Supports centralized cloud management through the Omada web interface and Omada app for simplified network administration.
• Extends PoE transmission up to 250 m (820 ft) in supported deployment scenarios, making it suitable for surveillance applications.
• Includes QoS, VLAN, IGMP Snooping, Port Isolation, PoE Auto Recovery, and automatic loop prevention to improve network performance and reliability.
• Features a fanless design, ensuring silent operation in offices and other noise-sensitive environments.
• Uses a durable metal housing with desktop and wall-mount installation options for flexible deployment.

Technical Specifications

• Brand: TP-Link
• Series: Omada
• Model: ES205GP
• Product Type: Easy Managed Gigabit PoE+ Switch
• Ports: 5 × 10/100/1000 Mbps RJ45 Ports
• PoE Ports: 4 × IEEE 802.3af/at PoE+
• PoE Power Budget: 65 W
• Maximum Power Per PoE Port: 30 W
• Management: Centralized Cloud Management via Web and Omada App
• Network Features:
  • VLAN
  • Quality of Service (QoS)
  • IGMP Snooping
  • Port Isolation
  • PoE Auto Recovery
  • Automatic Loop Prevention
• Extended PoE Distance: Up to 250 m (820 ft)
• Enclosure: Metal
• Cooling: Fanless
• Mounting Options: Desktop and Wall Mount

Common Applications

The ES205GP is suitable for small offices, retail stores, schools, hospitality environments, surveillance installations, and branch networks. It is particularly useful for powering IP cameras, wireless access points, VoIP phones, and other IEEE 802.3af/at-compliant devices while providing dependable Gigabit network connectivity and centralized management.

Why Choose This Product?

The TP-Link ES205GP combines Gigabit networking, PoE+, and essential management capabilities in a compact switch that is easy to deploy and maintain. Its cloud management, silent fanless operation, and intelligent Layer 2 features help improve network efficiency while reducing installation complexity. Furthermore, its durable metal construction and flexible mounting options make it suitable for a wide range of professional networking environments.

FAQs

1. How many PoE ports does the TP-Link ES205GP have?

The switch includes four IEEE 802.3af/at-compliant PoE+ ports that provide both power and Gigabit data connectivity to compatible powered devices.

2. What is the total PoE power budget?

The ES205GP provides a total PoE power budget of 65 W, with up to 30 W available on each individual PoE+ port.

3. Can the switch be managed remotely?

Yes. It supports centralized cloud management through the Omada web interface and the Omada app, allowing administrators to manage the switch remotely.

4. Is the switch suitable for surveillance networks?

Yes. It supports extended PoE transmission up to 250 m, along with Port Isolation and PoE Auto Recovery, making it well suited for many surveillance deployments.

5. Does the switch require a cooling fan?

No. The ES205GP features a fanless design, providing silent operation while reducing maintenance associated with moving cooling components.
