Hikvision DS-3E0508-O-8-Port Gigabit Switch

Description

• General
• ShellMetal material, fan-free design
• Net Weight0.24 kg (0.53 lb)
• Gross Weight0.37 kg (0.77 lb)
• Dimensions (W × H × D)145.00 mm × 25.60 mm × 68.45 mm (5.71” × 1.01” × 2.69”)
• Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
• Operating Humidity5% to 95% (no condensation)
• Relative Humidity5% to 95% (no condensation)
• Power Supply5VDC, 0.6A
• Max. Power Consumption3 W
• Power Consumption in Idle1.61 W
• Installation ModeDesk-Mounted,Wall-Mounted
• Surge Protection6 KV

• Network Parameters
• Ports8 × Gigabit RJ45 port
• MAC Address Table8 K
• Switching Capacity16 Gbps
• Packet Forwarding Rate11.90 Mpps
• Internal Cache4 Mbits

• PoE Power Supply
• PoE Standard/
• PoE Power Pin/
• PoE Port/
• Max. Port Power/
• PoE Power Budget/

• Dialing Function
• Long Range/
• Port Isolation/
• PoE Watchdog/

• Approval
• EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
• SafetyCB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
• ChemistryCE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
