The Cambium cnPilot™ E410 is an advanced, plenum-rated indoor access point designed to deliver high-performance wireless connectivity. Built with 802.11ac Wave 2 technology, it features 2×2 MU-MIMO (Multi-User, Multiple Input, Multiple Output) capabilities, making it ideal for dense environments where multiple devices need to connect simultaneously. The cnPilot E410 is engineered to support demanding enterprise applications, providing flexible and reliable coverage with the ability to utilize channels up to 80MHz wide on the 5 GHz band.

Key Features:

• Plenum-Rated Design: Safe for installation in air handling spaces such as ceilings.
• 2×2 MU-MIMO Technology: Supports multiple devices with improved data throughput and efficiency.
• Max Transmit Power of 25 dBm: Delivers strong signal strength for extended coverage.
• Dual-Band Operation: Operates on both 2.4 GHz and 5 GHz bands for better flexibility and performance.
• Up to 80MHz Channel Width on 5 GHz: Allows for high data rates and better utilization of the 5 GHz spectrum.
• Gigabit Ethernet Port: Ensures high-speed wired connectivity for backhaul or client devices.
• Supports up to 256 Users per Radio: Can handle multiple users without compromising on performance.
• Automatic Channel Selection: Ensures optimal channel usage for minimal interference.
• Seamless Roaming: Supports fast roaming between access points for uninterrupted connectivity in enterprise environments.
• Flexible Mounting Options: Can be mounted on walls or ceilings to suit various deployment scenarios.
• Centralized Management: Managed through cnMaestro™, providing easy configuration, monitoring, and management.

 Specifications:

• Wireless Standards: IEEE 802.11a/b/g/n/ac Wave 2
• MIMO: 2×2 MU-MIMO
• Operating Bands:
  • 2.4 GHz: 2400-2484 MHz
  • 5 GHz: 5150-5850 MHz
• Channel Widths:
  • 2.4 GHz: 20 MHz
  • 5 GHz: 20/40/80 MHz
• Max Transmit Power: 25 dBm (dependent on regulatory restrictions)
• Antenna Gain:
  • 2.4 GHz: 3 dBi
  • 5 GHz: 5 dBi
• Data Rates:
  • 2.4 GHz: Up to 300 Mbps
  • 5 GHz: Up to 867 Mbps
• Ethernet Port: 1x 10/100/1000 Mbps RJ45 port with PoE (Power over Ethernet)
• Power Supply: 802.3af/at PoE or 12V DC (adapter not included)
• User Capacity: Supports up to 256 clients per radio
• Security: WPA-PSK, WPA-TKIP, WPA2 AES, 802.1x, RADIUS, WIDS/WIPS
• Management: cnMaestro™ cloud or on-premises, SNMP v2/v3, CLI
• Dimensions: 180 x 180 x 39 mm (7.08 x 7.08 x 1.53 inches)
• Weight: 366g (12.9 oz)
• Environmental: Operating temperature: 0°C to +40°C, Humidity: 10% to 90% non-condensing
• Compliance: CE, FCC, RoHS

Applications:

• Enterprise Networks: Ideal for offices, schools, and hospitals requiring high-density wireless networks.
• Hospitality: Perfect for hotels, resorts, and restaurants needing reliable guest Wi-Fi.
• Retail: Suitable for stores and shopping malls offering Wi-Fi services to customers.

The Cambium cnPilot E410 is a versatile and powerful access point designed for modern enterprise environments. Its combination of robust performance, advanced features, and centralized management makes it a top choice for businesses looking to deliver seamless wireless experiences
