Yeastar S300 300 Users 60 Concurrent Calls Modular IP PBX

Part of Yeastar’s latest S-Series VoIP PBX line, it is easy to install, simple to manage and built to perform. You can save time with fast installation and maintenance because Yeastar’s S-series PBX can be streamlined using their advanced auto-configuration, auto-detect,and plug-and-play capabilities. They are also easily controlled and configured via intuitive and graphical UI and point-and-click online configuration panel. Everything can be managed via any internet enabled device.

Yeastar S-Series VoIP PBX provides flexible telephony interfaces combination while allowing for future scalability with the unique modular design. Besides the built-in rich SIP capabilities, S-Series lets you decide what types of extensions and physical trunks you need in your telephone system. When your business grows, adding more users and concurrent calls is also possible with S-Series. With Yeastar S-Series, all the telephony interfaces are modular and customizable, whether it’s FXS, FXO, ISDN BRI, GSM/3G, or E1/T1/PRI. S20 has two onboard module slots.

Yeastar S100 IP PBX Detailed Specification

• 300 users (expandable to 500) and 60 concurrent calls (expandable to 120)
• Includes 300 SIP trunks
• Add optional modules to activate additional ports up to 24 Analog, 24 BRI, 6 GSM, and 3 E1/T1/J1
• Includes 10,000 minutes of expandable voicemail storage
• Add up to 2 D30 modules to expand capacity by 100 extensions and 30 concurrent calls each
• 3 interfaces for expansion cards (EX08 1 PRI card or EX30 mounting card for 4 modules)
• Built-in call recording capability
• Add on powerful apps including auto provisioning, LDAP, and more
• Free lifetime software/firmware upgrades
• Connect multiple sites and remote users instantly
• No hidden charges or extra licensing fees
• Low power consumption at 6.2-59.1W
• Automated attendant (IVR)
• Email to SMS/SMS to email
• Fax to email
• Paging/intercom
• Mobility extension
• Music on hold
• SIP forking
• Voicemail to email
• 1U rack mountable

Yeastar S300 gives midsize enterprises a customizable IP-PBX for controlling telephony for 300 users and 60 simultaneous calls, all from a single rack-mounted device. The Yeastar S-Series VoIP PBXfeature a modular design. For the S300 that means that you can install three expansion boards, choosing from two options. The first option lets you integrate digital telephones into your VoIP system using the EX30 Expansion Board, which has a single E1/T1/PRI port. The second option is the EX08 Expansion Board, which features eight RJ11 ports and four card slots for modules. Each EX08 board can take four of the following modules:

• S2 Module: 2 FXS (analog)
• O2 Module: 2 FXO (analog)
• SO Module: 1 FXS / 1FXO (analog)
• B2 Module: 2 BRI (digital)
• GSM Module: 1 GSM (cellular)
• 3G Module: 1 UMTS (cellular)

Note that the S300 only has six antenna sockets, so you can install a maximum of six GSM/3G cellular modules across the three expansion boards.

You can also add support for users and concurrent calls without getting another IP-PBX simply by installing a D30 Module, which is a digital signal processor (DSP) that adds support for 100 users and 30 concurrent calls. The S300 has two slots for D30 Modules, so you can expand the S300 to control an incredible 500 users.

How does Yeastar power all this? Using an industrial-grade Freescale Quad Core processor with TI DSP and dual Gigabit Ethernet ports. Multicolor LED lights let you know at a glance what each RJ11 port is being used for and its status. The S300 runs SIP, giving you a vast selection of service providers to choose from. The PBX provides advanced telephony controls such as ring groups, video calls, call monitoring, automated attendants, fax to email, and many more. The system is simple to manage using a graphical UI that can be accessed anywhere through the web. BYOB offices will love the ability to bring mobile devices into the office’s VoIP phone system using the Linkus Mobile Client for Android and iOS. The S300 includes an integrated firewall, as well as support for the secure TLS and SRTP transfer protocols. The S300 is a 1U rack-mounted device. You can add a 2.5″ SATA HDD internally for extra storage.

Yeastar S100 VoIP PBX Quick Specs:

• Communications Protocols: SIP (RFC 3261), IAX2
• Ethernet Ports: 2x 10/100/1000 Gigabit
• Additional Ports: 6x antenna sockets, 1x USB, 1x console, 1x SD card slot
• Users: 300 (expandable to 500 with D30 Module/s)
• Concurrent Calls: 60 (expandable to 120 with D30 Module/s)
• FXS/FXO Ports: up to 24 (with O2, S2 or SO module/s)
• E1/T1/PRI Ports: up to 4
• BRI Ports: up to 24 (with B2 module/s)
• GSM Channels: up to 6 (with GSM module/s)
• 3G Channels: up to 6 (with 3G module/s)
• Audio Codecs: G.711µ/a, G.722, G.726, G.729A, GSM, Speex, ADPCM, iLBC
• Video Codecs: H.263, H.263P, H.264, MPEG4
• Fax-over-IP: T.38
• External Storage: via additional 2.5″ SATA HDD
• Dimensions: 17.32″ x 9.92″ x 1.73″
• Mounting: rack

Yeastar S300 300-User Expandable VoIP Phone System Package Contents:

• S300 IP-PBX
• Ethernet cable
• 2x rack-mounting kits
• Power cord
• Grounding stud and nut
• 4x rubber feet
• Quick start guide
• Warranty card

Yeastar S300 is a stand-alone telephone system offering an unrivaled range of features to large business with less than 300 (up to 500) users. It supports 60 (up to 120) concurrent calls and various combinations of telephony ports including FXS, PSTN, ISDN BRI, and GSM/3G. This guide describes how to install the S300 and how to log in the web GUI to configure the system. Once you complete the installation, refer to the Yeastar S-Series Administrator Guide for instructions on how to perform configurations on the system.

Designed with the small and medium-sized enterprises in mind, supporting up to 500 users and built using the very latest technology, the Yeastar S-Series delivers exceptional cost savings, and productivity and efficiency improvements to small and medium-sized businesses, delivering power, performance, quality,and peace of mind.

Completely redefined, Yeastar S-Series is powered by the latest processor technology, with industrial grade Freescale A9 Quad Core CPU chipset and Texas Instruments DSP voice processors. The all-new S-Series is designed for the needs of today and with the Yeastar unique modular design future proofs your investment choice.

With the latest software upgrade to Asterisk 13 which is packed with new features, the Yeastar S-Series delivers greater productivity improvements for your business, and with no ongoing software subscription costs, ever.

Yeastar S300 IP PBX delivers enterprise-class IP telephony services with a base configuration that supports 300 users and can be expandable to 500 users. Yeastar  S300 grows with your business and supports up to 24 analog ports, up to 24 BRI ports, up to 3 E1/T1/PRI ports, and up to 6 GSM channels. S300 Supports D30 Module of increasing the Capacity and EX30 PRI Module. S300 delivers enterprise-class IP telephony services with a base configuration that supports 300 users. Expandable to 500 users, S300 grows with your business and supports up to 24 analog ports, up to 24 BRI ports, up to 3 E1/T1/PRI ports, and up to 6 GSM channels.

Yeastar S300 Features in Detail

Yeastar S300 IP PBX System provides two 10/100/1000 Mbps  RJ45 Network ports and 3 Chasis expansion card slots. This rack-mountable IP Telephone system can be rack mount and come with the easy to use new Yeastar configuration WEB GUI. Initially, the S300 support 300 users and can be expandable to 500 users by adding the D30 DSP Card. Yeastar  S300 grows with your business and supports up to 24 analog ports, up to 24 BRI ports, up to 3 E1/T1/PRI ports, and up to 6 GSM channels. My PBX S300 have three chassis expansion card slots and can use as the modular solution by your choice of cards. The inbuilt conference bridge can be very helpful for many businesses. Yeastar S-Series supports call recording that is very effective in case you want to monitor the business activity or use it for training purposes.

The GUI Based call recording giving you access virtually anywhere from the world. The same applicable for inbuilt call detail records as well. The Yeastar S Series also include the features like set the system’s email to send voicemail to email, alert event emails, fax to email, email to SMS and SMS to email.Yeastar S300 VoIP PBX offers versatile telephony user interfaces mix while permitting future scalability with the special modular design. Besides the integrated rich SIP capacities, S300 allows you to decide exactly what types of extensions and physical trunks you require in your telephone system. When your business expands, including more customers as well as simultaneous calls is also possible with S300. With Yeastar S300 all the telephone user interfaces are modular as well as adjustable, whether it’s FXS, FXO, ISDN BRI, GSM/3G, or E1/T1/PRI. The System capacity can additionally enhance with D30 Cards.D30 is a DSP component, utilized to expand the capacity of PBX. With each D30 module included, the extensions increase 100, as well as boost 30 in additional concurrent calls.

Powered by the newest processor innovation, Yeastar’s S300 PBX is a count on deserving telephone system with one of the highest possible MTBF (Mean Time In between Failings) in the industry. Based on Asterisk 13, S300 is born to be powerful and regularly fulfilling your communication needs.With progressed failover, safety and security, surveillance and reporting capacities as typical, incorporated with an interior firewall and also with support for TLS and SRTP file encryption, there has actually never been such a robust system.It is the best telephone system to choose as your office telephone system.
